Want an 8-ton excavator that can go 25 mph? Try out the Tier 4 Final 590 Super N backhoe loader. The backhoe delivers breakout of nearly 16,000 lb. as well as a digging depth of up to 20 feet and a lifting capacity of more than 4,100 lb. The heavy-duty loader gets it done with breakout forces of nearly 13,700 lb. and with the responsive PowerDrive transmission, you have more speed and performance at your control. The 590SN comes standard with PowerLift, ProControl swing dampening, ECO Mode, SiteWatch™ Telematics and the breakthrough PowerBoost feature to help tear through tough ground.
Productivity
Our strongest backhoe loader is all about productive power. With the push of a button, PowerBoost gives a temporary surge of hydraulic digging power. The PowerDrive transmission features seamless, automatic drive engagement for greater speed and gradeability under load, and PowerLift provides steady strength when craning. A universal hydraulic quick coupler works with most backhoe attachments and a factory-fit hydraulic thumb is also available for added utility.
For trenching or precision applications, standard ProControl helps stop the arm where you want without excess rebound. With loader work, several options work together to help save time and reduce spillage; Comfort Steer cuts lock-to-lock turns in half, adjustable Auto-Ride Control reduces load shock at speeds you set and our exclusive over-center design helps minimize “porposing” during road travel.
Fuel Efficiency
Simply put, SCR (Selective Catalytic Reduction) means power. As an after-treatment Tier 4 Final solution, it provides compliance and fuel savings without sacrificing engine performance with no regeneration downtime or extra fuel burn, which is what you want with higher-horsepower backhoes. The 590 Super N also comes standard with fuel-efficient ECO Modes for both loader and backhoe, as well as adjustable engine Auto-Idle and Auto-Off settings.
Comfort and Visibility
The 590SN offers a premium, multi-colored air-ride seat with lumbar support and heat, as well as a Bluetooth radio with USB to keep operators comfortably productive. Backhoe controls are available as classic foot swing controls, dual-lever mechanical controls or pilot controls, which can be adjusted independent of the wrist rests. Loader controls put important functions at your fingertips like a rocker FNR switch, which lets you shift directions while keeping a hand on the steering wheel. A low-profile hood and floor-to-ceiling glass with opening rear-quarter panels (w/cabs) provide excellent visibility to buckets and around the machine, and optional LED lights provide more illumination with less power drain.
Serviceability
We’ve made it easy to keep our most powerful backhoe running at peak performance. You can quickly check or fill engine oil, transmission fluid or coolant, and fill up the fuel and DEF tank, all from the ground. The brakes can be serviced without complete axle disassembly and externally adjustable Extendahoe® wear pads allow you to tighten tolerances on-site with simple tools. Plus, with the SCR solution, there’s no particulate filter to maintain or replace. And for added security and convenience, all N Series backhoes come with a battery disconnect switch and jumpstart terminal.
For more information, check out the 590 SUPER N brochure.
Standard Equipment
Operator Environment
- ROPS/FOPS certified protective canopy
- Anti-vandalism cover for dash – w/ canopy only
- Rear fenders extensions
- Coat hook w/ garment strap
- Interior rearview convex mirror
- Mechanical suspension seat – 180° swivel – Vinyl
- 3 in (76 mm) retractable seat belt
- Cup holder/ storage tray mounted on left-hand fender
- Right-hand storage compartment w/ lid, tilt-steering wheel on cab models
- Gauges:
- Engine water temperature
- Converter oil temperature
- Fuel level
- Tachometer/ hourmeter
- DEF level
- Warning lights:
- Air cleaner restriction
- Alternator
- A/C high pressure
- Cold start
- Engine oil pressure
- Hydraulic oil filter bypass
- Parking brake engagement
- Low fuel
- Water in fuel
- Low DEF
- Audible alarms w/ diagnostics:
- Coolant temperature
- Engine oil pressure
- Parking brake engagement
- Converter oil temperature
- Shuttle engagement/seat position
- Backup alarm
- Low DEF
- Horn
- Dual switched front and rear
Loader
- Bucket position indicator;
- Lifting lugs and tie downs on standard bucket;
- Single lever control with self-leveling and return-to-dig;
- Hand operated clutch disconnects on loader and shift levers, single lever 4-function loader control: lift, dump, clutch cut-out, differential lock and FNR switch
Backhoe
- Over center design, Fabricated “S” boom
- Pro Control System
- Dipperstick integrated serrated gripper teeth
- Case mechanical coupler
- Power Lift, Power Boost
- Cleated dirt stabilizer pads
- Extendahoe®
Warranty
- 1-Year/Unlimited-Hour Full-Coverage Base Limited Warranty
- 2-Year/2,000-Hour Extended Engine Warranty
Engine
- FPT F5BFL413A diesel
- Selective Catalytic Reduction – SCR
- Aspirated air cleaner – replaceable dual element dry type with radial seal
- Fuel filter with water trap
- Radiator with de-aeration bottle
- Antifreeze to -34° F (-37° C)
- Electronic throttles – foot and rotary hand
- Self adjusting belt
- High Pressure Common Rail computer controlled injection with diagnostic features
- Engine ECO Mode – Detent on backhoe hand throttle, push button switch on dash
- Auto Engine Idle
- Auto Engine Shutdown
- Auto Protection Shutdown
- Electronic Fuel Priming
- Cold Weather Starting Aid: Dual 12 volt batteries, glow plugs, engine block heater and heated CCV hose
Drivetrain
- PowerDrive H-Type transmission, 4F-4R, hydraulic clutch shifting, kick down, transmission disconnect and FNR switch in loader control lever, includes auto shift mode and direct drive
- Front axle:
- 4WD heavy-duty mechanically driven front axle with 14.0 L x 17.5 tires and drive shaft guard
- Rear axle:
- 4WD heavy-duty outboard planetary drive, with 21.0 L x 24.0 tires
- Torque converter – 11.8 in (300 mm)
- On-the-go electric 4WD control
- Electric F/R shuttle control
- Electric differential lock control, push-button
- Park brake, spring-applied hydraulic release – SAHR
Hydraulics
- Ground level remote hydraulic test ports
- Variable displacement axial piston pump
- Pump:
- 43 gpm @ 3,000 psi
- (162.6 L/min @ 207 bar)
- Heavy-duty hydraulic oil cooler
- 7-micron, spin on oil filter
Other
- Front tire 14.0 L x 17.5, 10 PR – 4WD
- Rear tire 21.0 L x 24.0, 10 PR
- Forward tilt engine hood
- Replaceable, molded front bumpers
- Front/Rear tie downs
- Reflective logos
- Signal Lights – cab and canopy:
- 2 rear tail /stop
- 2 front flashers/turn
- 2 rear flashers/turn
- Working/Driving Lights – cab and canopy:
- Adjustable halogen work lights – 55 W:
- 4 front
- 2 side – one left, one right
- 4 rear
- Adjustable halogen work lights – 55 W:
- Master disconnect switch and remote
- Jump-start terminals
- Hydrostatic steering
- Backup alarm
- Vertical spin-on engine oil, fuel and hydraulic filters
- Locking DEF/Fuel covers
- Tool box – bolt-on, step-mounted
Telematics
- CASE SiteWatch™ Telematics – includes hardware and a 3-yr Advanced data subscription
Optional Equipment
Backhoe
- 1-way/2-way Auxiliary backhoe hydraulics for hammers, plate compactors or similar 1-way flow attachments or switch to 2-way flow for thumbs, augers or similar 2-way flow attachments
- Bolt-on hardened gripper teeth
- Two-lever control
- Pilot operated control system:
- Fingertip proportional Electro-Hydraulic stabilizer controls
- Thumb-operated proportional
- Electro-Hydraulic Extendahoe® control
- Thumb-operated horn button
- Thumb-operated auxiliary hydraulic control
- Infinitely adjustable towers
- In-cab switchable “excavator to backhoe” control pattern change Standard dipper
- Flip over stabilizer pads
- Hydraulic bucket coupler
- Universal coupler – CAT/Deere compatible
- Buckets
- Hydraulic thumb – Includes: 2 replaceable, high strength, bolt on tines with two positions for Universal or Hi-Cap buckets – meshes with Bucket teeth on 18 in & 24 in Buckets
Engine
- Severe Cold Weather Starting Aid: Synthetic transmission, hydraulic and engine oil – order with cold weather starting aid
Operator Environment
- Speed Selectable Auto Ride Control – 4WD models
- Comfort Steering with two-speed steering pump and 3rd/4th gear cutout
- ROPS/FOPS certified protective cab available in LH Door or 2 door with heat, A/C, defroster, door activated dome light, 4 front, 4 rear and 2 adjustable side lights, floor mat, tinted glass, bluetooth radio, front and rear wiper and fender extensions
- Deluxe Cab package included on 2-door cabs includes: deluxe interior, viscous fan, pull-down sun visor and 72 dba sound level
- Premium multi-color, hand stitched cloth, heated air suspension seat – not for use with ROPS Canopy option
Other
- Front tires:
- 14.0 L x 17.5 10 PR
- Rear tires:
- 21 L x 24, 10 PR or 540/70 R24 Michelin
- Special paint
- LED Working/Driving Light Package:
- 4 front
- 4 rear
- 2 side
- Front fenders
- Special feature request
Loader
- Auxiliary hydraulics for loader-mounted equipment with thumb-operated proportional control
- Hydraulic front quick coupler
- Loader linkage without loader bucket
- Tool portfolio of additional attachments
- Buckets
